Over the Air tab

PC12114-UN-09JUN09

A - Readings tab

B - Data Logs tab

C - Over the Air tab

D - Radio Self Test tab (North America Only)

E - Over the Air Messages

F - Message History

G - Clear History button

Over-the-Air (OTA) messages allow the StarFire 3000 to receive licenses and activations through the StarFire network. Rather than getting a license code over the phone or the internet, the license code is transmitted wirelessly from a StarFire satellite.

The operator must first go to StellarSupport website and enter a request to be send the license immediately or after a certain time delay. In either case, the receiver must be powered up and tracking satellites to accept the Over-the-Air activation. If the activation does not successfully load, the user should call StellarSupport to have the activation re-generated.

Message History (F)— Shows OTA messages that have been received since the receiver has been powered on. History shows whether an OTA activation was applied successfully or not.

Clear History button (G)— Erases the OTA message history.
