DIAGNOSTIC softkey

PC8663-UN-05AUG05

MENU button

PC13006-UN-08NOV10

StarFire 3000 button

PC13049-UN-10NOV10

DIAGNOSTIC softkey

The StarFire 3000 - Diagnostic screen contains three tabs:

READINGS tab

DATA LOGS tab

OVER THE AIR tab

READINGS tab has detailed information about receiver.

• Unswitched voltage
• Switched voltage
• CAN High voltage (Vehicle Bus)
• CAN Low voltage (Vehicle Bus)
• Software Part Number
• Software Version Number
• Hardware Part Number
• Hardware Serial Number
• Receiver Hours (h)
• Receiver Address
• QuickStart Status
• External Antenna
• Serial NMEA

The following reading only appears when receiver has a RTK activation.

• RTK Software Version Number (RTK Radio Software Version)
• RTK Serial Number (RTK Radio Serial Number)
• RTK Status
• RTK Search Time (sec.)
• RTK Satellites in Search (above 10 degrees elevation)

DATA LOGS tab has graphed GPS data, logged over the previous 60 minutes.
