Control Valve Test

PC12379-UN-03NOV09

Control Valve Test

A - Tests Drop-Down Menu

B - - Button

C - + Button

D - Control Valve Test Status

This test operates the control valve without dispensing product.

Press and hold the - or + button to operate the valve.

NOTE: Not available for Fast Close control valve type.
