ISOBUS Agricultural Industry Electronic Foundation (AEF) Certification
ISOBUS AEF Certification is an international standard for agricultural electronic applications. With it enabled, GreenStar™ 3 2630 Display with Section Control can control third-party implements with ISO Task Control-Section Control functionality.Implement manufacturer determines ISOBUS AEF Certification compatibility. Contact implement manufacturer for compatibility details. ISOBUS AEF Certification functionality is only approved for 30 series and newer John Deere tractors.
PC21884-UN-03DEC15
ISOBUS Certification Button
PC21885-UN-03DEC15
Save Settings and Restart Display Button
The ISOBUS AEF Certification checkbox is located in Multiple Displays Settings. Select Menu button > Display button > Display Diagnostics softkey > Multiple Displays tab > Change Settings button > Next button > ISOBUS Certification checkbox > Save Settings and Restart Display button.NOTE: ISOBUS AEF Certification disables the use of the Original GreenStar™ Monitor within the GS3 2630 Display. Controllers that are designed for use with the Original GreenStar™ Monitor are disabled.
|
