Obtain Activation Code and Activate Software on Display

PC8663-UN-29APR15

Menu button

PC17340-UN-24OCT13

GreenStar™ 3 PRO button

PC17335-UN-23OCT13

GreenStar™ 3 PRO softkey

NOTE: The display Serial Number and Challenge Code are found at Menu button > GreenStar™ GreenStar™ 3 Pro button > GS3 button > Activations tab.

Get the 6-digit Comar order number from your dealer for the GS3 Pro package you have purchased (AutoTrac™ , PivotPro, John Deere Section Control).

Get the serial number and challenge code from the display.

Go to deere.com and select Activations and Subscriptions.

Select GreenStar™ 3 > Activate AutoTrac™, then follow the GreenStar™ 3 Software Activation prompts to obtain the 26-digit code.

On the display, go to: Menu > GreenStar™ 3 Pro button > GreenStar™ 3 Pro button > Activations tab

Input the activation code.

Display shows as Activated in the Pro Module area.

The Display Software Activation Process is completed. Keep in mind if you have purchased SF2 level AutoTrac™, you are required to also activate the StarFire™ Receiver to an SF2 level. The StarFire™ is a separate 24-digit activation for SF2 and RTK.
