Application Controller 1100—Setup Softkey

PC21157-UN-11MAY15

Setup Softkey

• Control Selection—Select control type for selective control valve (SCV) 1 or SCV 3.
• SCV Threshold Setup—Enter extend and retract threshold and valve test on or off.
• Serial Port Setup—Set up serial port communications.
• I/O Voltages—View Input / Output (I/O) voltage readings.
• Activation Entry—Enter Application Controller 1100 specific activations.
