Mast (Rear) and Boom, Right-Hand Side (120R Loader)

W27187-UN-16DEC15

W07229-19-28MAR05
(A)

W08901-19-21SEP07
(B) Both Sides
(A)—Danger: Serious injury or death
can result from rollovers.
-
Do not handle round or large square bales.
-
Use ROPS and seatbelt at all times.
-
Add required rear ballast.
-
Move wheels to widest recommended setting.
-
Operate tractor at low speeds.
(B)—Warning: To avoid injury from
falling loader:
-
Do not walk or perform service under a raised loader.
-
Lower loader to ground when parked.
Do not operate loader without engaging attachment latch.
Failure to engage retainer could result in attachment detaching
from loader causing serious bodily injury or death.
|
|
OUO6064,0002114-19-20180626
|
|
