Check Engine Oil Level

1. Park tractor on level ground, put range shift lever in neutral (N), set brakes and pull fuel shut-off knob to stop engine

2. Pull out dipstick (A). Oil level should be between two marks on dipstick. DO NOT operate engine when oil level is below low mark on dipstick.

3. If level is low, add oil through oil filler hole (B) until even with upper mark. DO NOT overfill. (See fuels, Lubricants and Coolants section.)


A-Engine Oil Dipstick
B-Engine Oil Filler Hole

PY4035
PY4036

AG,OUO1032,2546 -19-21AUG99-1/1
