Rear Wheel Rim-to-Disk (Late Model Steel 24" & 28" Wheels)
-Torque
|
245 N·m (180 lb-ft)
|
|
Rear Wheel Rim-to-Disk (Late Model Steel 18.4-30 & 15.5-38 Wheels)
-Torque
|
350 N·m (255 lb-ft)
|
|
Rear Wheel Rim-to-Disk (Early Model Steel Disk) Bolts
-Torque
|
245 N·m (180 lb-ft)
|
|
Rear Wheel Rim-to-Disk (Cast Disk) Bolts
-Torque
|
215 N·m (160 lb-ft)
|
|
Rear Wheel Rim-to-Disk (Veggie Disk) Bolts (Early Model Tractor)
-Torque
|
235-250 N·m (175-185 lb-ft)
|
|
Rear Steel Wheel Disk-to-Hub M16 Bolts
-Torque
|
175 N·m (130 lb-ft)
|
|
Rear Steel Wheel Disk-to-Hub M20 Bolts
-Torque
|
600 N·m (445 lb-ft)
|
|
Rear Cast Wheel Disk-to-Hub M16 Bolts
-Torque
|
225 N·m (165 lb-ft)
|
|
Rear Wheel Disk-to-Hub (Veggie Disk) Bolts (Early Model Tractor)
-Torque
|
200 ± 40 N·m (148 ± 30 lb-ft)
|
