Enable/Disable Softshift

RXA0103941-UN-24JUL09

Transmission

RXA0112385-UN-21DEC10

A - Shift Set Point Indicator

B - Reverse/Forward Speed Ratio

C - Startup Gear

D - Softshift

E - PTO Adjust

F - Speed Matching

The Softshift (D) feature provides smoother shifting between gears by providing short intermediate engine rpm adjustments between each gear shift.

• During an upshift, engine rpm will momentarily decrease at the beginning of the shift and then increase to the current throttle.
• During a downshift, engine rpm will momentarily increase at the beginning of the shift and then decrease to the current throttle.

Press transmission softkey.

The momentary change in engine rpm may not be desirable during constant PTO rpm applications. If constant PTO rpm is desired, the operator should deactivate PTO Adjust (E) check box.
