Premium Radio Source Select on the CommandCenter™

RXA0098156-UN-07NOV08

RXA0113069-UN-18JAN11

Radio Menu Icon

RXA0113164-UN-18JAN11

Source Select Page

A - CD/MP3

B - USB

C - AUX

D - FM

E - AM

When the radio is OFF, selecting the radio menu icon will navigate to the Source Select page. Selecting a source from the Source Select page will turn the radio ON to that selected source.

When the radio is ON, selecting the radio menu icon will navigate to the currently selected source’s home page.

Selecting the Source Select page softkey from a radio home page will navigate to the Source Select page. Selecting a source from the Source Select page will change the radio to that selected source.
