Setting Front And Rear PTO Engagement Rates

1. Select CommandArm Menu Button.

2. Select PTO.


   RXA0116587-UN-12MAY11

   PTO Short Cut Button


   RXA0120021-UN-01SEP11

   PTO Advanced Page

   A - Rear PTO Engagement Rate Drop Down Box

   B - Front PTO Engagement Rate Drop Down Box

   C - Back Softkey

   NOTE: When FieldCruise setting soft key (A) is selected FieldCruise settings drop down box (B) is highlighted and engine speed can be adjusted.

---




3. Select Settings softkey.

4. To change Rear PTO Engagement rate, select double arrow in Rear PTO Engagement Rate drop down box (A).

   To change Front PTO Engagement Rate drop down box (B).

   Engagement rate options are

   • Auto
   • Low Rate
   • High Rate



5. Select rate required.

6. Select Back softkey to return to PTO page when finished.
