Driving Tractor on Roads

CAUTION: Avoid personal injury or death from losing control of tractor. When driving tractor on roads:

RXA0086597-UN-09FEB06

• Wear Seat belts
• Couple brake pedals together
• If equipped, use foot throttle instead of hand throttle
• Reduce speed when driving on icy, wet, or graveled surfaces
• Ballast tractor correctly (See Performance Ballasting section)
• Prevent wheels from locking and skidding on tractors equipped withAutoPowr™ transmission. (See Downhill Operation In Slippery Conditions, in Operating AutoPowr Transmission section.)
• Avoid holes, ditches, sharp turns, hill sides and obstructions which may cause tractor to roll over.
• Frequently check for traffic from the rear, especially in turns, and use turn signal lights.
• Always operate flashing lights when traveling on a highway or public roads, except where prohibited by law.

Lights—Use headlights and turn signals day and night. Follow local regulations for equipment lighting and marking. Keep lighting and marking visible and in good working order. Replace or repair lighting and marking that has been damaged or lost. An implement safety lighting kit is available from your John Deere™ dealer.

Brakes—Tap brake pedal to ensure differential lock is NOT engaged. Couple brake pedals together before driving on a road. Avoid hard application of brakes.

MFWD—Disengage front wheel drive when transporting tractor. When driving on roads, engage AUTO or BRAKE ASSIST position of MFWD switch to provide four wheel braking.

Remote Cylinders—Position transport lock switch(es) to eliminate possibility of lowering an implement during transport by inadvertently bumping the extend/retract lever(s). (See procedure in Hydraulics and Selective Control Valves or TouchSet™ Depth Control section.)

Front or Rear Hitch—Position or lock hitch in transport position to eliminate possibility of lowering an implement during transport by inadvertently bumping the raise/lower lever. (See procedure in Hitch section.)
