Checking Wheel and Weight Bolts

RXA0119680-UN-11AUG11

SERVICE INTERVAL — 500 HOURS

IMPORTANT: If tractor is operated with loose wheel sleeve for 4-5 hours, it is necessary to replace sleeves.

Retighten wheel and weight bolts after working 3 HOURS, 10 HOURS and DAILY during the first week of operation.

Check and torque all wheel and weight bolts on a regular or 500 Hour interval. See Wheels, Tires and Treads Section for bolt tightening information.
