Float Operation

Implements that fully rest on gauge wheels for depth control require hitch to float following ground contour.

Put hitch control lever in float position.

RXA0142717-UN-01JUL14

Rear Hitch Module in Float Position

A - Float Icon

NOTE: Hitch position indicator indicates actual hitch position.

Target position is 0%.

Lift links can be adjusted for lateral float. See lateral float in this section of this Operator’s Manual.
