Hitch Remote Switches

RXA0141371-UN-08MAY14

Hitch Remote Raise/Lower Switches on Rear Left Fender

A - Remote Hitch Raise Switch

B - Remote Hitch Lower Switch

CAUTION: To prevent injury or damage caused by tractor movement, be sure transmission is in PARK position before using remote raise/lower switches. Stay clear of interference points when using remote raise/lower switches.

NOTE: Hitch moves at slower speed when using remote raise/lower switches.

Rear hitch remote raise/lower switches (A, B) are located on left-hand side rear fender.

Use remote raise/lower switches (A, B) for hitch adjustments.
