Weight Chart - Narrow Track
Avoid physical injury or equipment damage. Never exceed
maximum listed speed for load at drawbar and rear axle.
Failure to follow road transport recommendations could cause track damage and void warranty.
- Attachments such as chemical tanks can add significant axle loads.
- Never exceed tractor’s or implement’s maximum transport speed. Speed is based on tractor capability.
- Speed settings can be locked. See Users and Access in the CommandCenter section of this Operator's Manual.
Loads listed in table are for reference only. Weigh front and rear axles individually when payload is added - include front-mounted spray tanks.
RXA0160969-UN-24OCT17
|
Weight and Recommended Speed with Suggested Implements |
|||||
|---|---|---|---|---|---|
|
Application |
Implement |
Weight/Load kg (lb) |
Maximum Transport Speed km/h (mph) |
||
|
Drawbar/Hitch |
Rear Axle |
Tracks |
|||
|
18 inch |
24 inch |
||||
|
Secondary Tillage |
60’ 2410C applicator |
181.4 (400) |
13607.7 (30000) |
41.8 (26) |
41.8 (26) |
|
Primary Tillage |
9 shank 2720 (Without Rolling Baskets) |
226.8 (500) |
13607.7 (30000) |
41.8 (26) |
41.8 (26) |
|
Primary Tillage |
11 shank 2730 (Gangs, Without Rolling Baskets) |
219.5 (484) |
13607.7 (30000) |
41.8 (26) |
41.8 (26) |
|
Secondary Tillage |
45’ 2210LL cultivator |
498.9 (1100) |
14061.3 (31000) |
41.8 (26) |
41.8 (26) |
|
Secondary Tillage |
40’ 2623VT |
816.5 (1800) |
14514.9 (32000) |
41.8 (26) |
41.8 (26) |
|
Secondary Tillage |
60’ 2510L 2400 gal (empty) |
1636.6 (3608) |
15422.1 (34000) |
35.4 (22) |
41.8 (26) |
|
Secondary Tillage |
45’ 2310 Mulch Finisher |
1905.1 (4200) |
15875.7 (35000) |
33.7 (21) |
41.8 (26) |
|
Other |
1500 bu Grain Cart Empty |
1723.6 (3800) |
15875.7 (35000) |
33.7 (21) |
41.8 (26) |
|
Other |
1500 bu Grain Cart Loaded |
2494.7 (5500) |
16782.8 (37000) |
30.5 (19) |
41.8 (26) |
|
Planters |
DB60 24R30 CCS |
3492.6 (7700) |
18143.6 (40000) |
28.9 (18) |
40.2 (25) |
|
Planters |
DB60 47R15 CCS |
3782.9 (8340) |
18597.2 (41000) |
27.3 (17) |
38.6 (24) |
|
Planters |
DB90 36R30 |
5579.2 (12300) |
20865.1 (46000) |
25.7 (16) |
37.0 (23) |
|
Planters |
1775NT 24R 2-Point Hitch |
5896.7 (13000) |
21318.7 (47000) |
24.1 (15) |
35.4 (22) |
|
Planters |
DB120 48R30 |
7983.2 (17600) |
24493.9 (54000) |
20.9 (13) |
32.1 (20) |
|
BH38674,0000BFB-19-20171102 |
