Install Clevis Assembly — Category 5 Drawbar

Avoid equipment damage: correctly attach clevis assembly.

  1. RXA0141899
    RXA0141899-UN-05JUN14

    Attach clevis assembly (A) to top of drawbar.


  2. Tighten two center M24 cap screws (B) to 750 N·m (553 lb·ft).

  3. Tighten four outer M20 cap screws (C) to 610 N·m (450 lb·ft).

TO84419,0000106-19-20170713
