Replace Warning Light Bulb-Open Station

NOTE: Bulb replacement procedures for front and rear warning lights are the same. Rear left-hand warning light shown.

1. Remove screws and warning light lens (A).

2. Push and twist bulb to release from socket.

3. Replace bulb.

4. Install lens and screws.

B-Warning Light Lens

AG,OUO1043,291 -19-16JUN00-1/1
