Using a Booster Battery or Charger

TS204-UN-15APR13

Exploding Battery

RG24885-UN-17DEC13

A - Series

B - Parallel

A 12 volt booster battery can be connected in parallel (B) with battery(ies) on the unit to aid in cold weather starting. ALWAYS use heavy-duty jumper cables.

Series:

• Amps = Same as single battery
• Volts = Twice as a single battery

Parallel:

• Amps = Twice as a single battery
• Volts = Same as a single battery

CAUTION: Gas given off by battery is explosive. Keep sparks and flames away from battery. Before connecting or disconnecting a battery charger, turn charger off. Make last connection and first disconnection at a point away from battery. Always connect NEGATIVE (–) cable last and disconnect this cable first.

IMPORTANT: Be sure that polarity is correct before making connections. Reversed polarity will damage electrical system. Always connect positive to positive and negative to ground. Always use 12 volt booster battery for 12 volt electrical systems and 24 volt booster battery(ies) for 24 volt electrical systems.

1. Connect booster battery or batteries to produce the required system voltage for your engine application.

   NOTE: To avoid sparks, DO NOT allow the free ends of jumper cables to touch the engine.

2. Connect one end of jumper cable to the POSITIVE (+) post of the booster battery.

3. Connect the other end of the jumper cable to the POSITIVE (+) post of battery connected to starter.

4. Connect one end of the other jumper cable to the NEGATIVE (–) post of the booster battery.

5. ALWAYS complete the hookup by making the last connection of the NEGATIVE (–) cable to a good ground on the engine frame and away from the battery(ies).

6. Start the engine. Disconnect jumper cables immediately after engine starts. Disconnect NEGATIVE (–) cable first.
