Required Machine Stop Warning


Machine Stop Mandate Occurs

RG22491
RG22491-UN-21AUG13

IMPORTANT: In some situations, machine engine power is reduced as described. On notification, immediately place the machine in a safe state and or move it to a safe location. A mandated machine stop can only be removed by a service technician.

Engine Emissions System Malfunction Indicator illuminates when an emission-related fault occurs.

RG22492
RG22492-UN-21AUG13

Warning Indicator illuminates when a condition exists which requires operator action.

RG22493
RG22493-UN-21AUG13

Engine Stop Indicator illuminates when a condition exists which requires immediate operator action and service.


Emission System Fault Has Occurred

RG26361
RG26361-UN-04SEP14

0—2 hours, the Engine Emissions System Malfunction and Warning Indicators are illuminated to warn operator of presence of emissions-related fault. If equipped, an alarm sounds.

RG26972
RG26972-UN-26MAR15

After 2 hours, performance is reduced. Engine Emissions System Malfunction and Engine Stop Indicators are illuminated to warn operator of emissions-related fault. If equipped, an alarm sounds. Full machine performance is restored with Ignition OFF, Engine OFF, Ignition ON, Engine ON.

RG26972
RG26972-UN-26MAR15

After 3 hours 50 minutes, performance is reduced. Engine Emissions System Malfunction and Engine Stop Indicators are illuminated to warn operator of emissions-related fault which has not been corrected. If equipped, an alarm sounds.


Emission System Fault Occurs Within 40 Hours of Previous Fault

RG26972
RG26972-UN-26MAR15

0—10 minutes, performance is reduced. Engine Emissions System Malfunction and Engine Stop Indicators are illuminated to warn operator of emissions-related fault. If equipped, an alarm sounds. Full machine performance is restored with Ignition OFF, Engine OFF, Ignition ON, Engine ON.

RG26972
RG26972-UN-26MAR15

30 minutes, performance is reduced. Engine Emissions System Malfunction and Engine Stop Indicators are illuminated to warn operator of emissions-related fault which has not been corrected. If equipped, an alarm sounds.

DX,MACHSTOPWARN,OEM-19-20151002
