Change Engine Speeds

PY42562-UN-31JUL17

Hand Throttle

APY21556-UN-06JUN20

Foot Throttle

A - Hand Throttle

B - Foot Throttle

To increase speed, push hand throttle (A) forward.

To temporarily increase engine speed above hand throttle setting, depress foot throttle (B).

NOTE: Floor mat is applicable for 5310, 5405, 5210, 5210 GearPro 4WD V1 models with TSS transmission.
