Service Intervals

PY5833
PY5833-UN-26FEB07

Every 10 Hours

  • Check engine oil level
  • Check coolant level
  • Drain water and sediment from fuel filter
  • Lubricate tie rod ends1
  • Lubricate steering spindles1
  • Lubricate front axle pivot pin(s)1
  • Lubricate rear axle bearings1
  • Lubricate clutch pedal and right hand brake pedal. 2
  • Lubricate cluch / brake shaft. 2

    IMPORTANT: External lubrication is not required for oil type rear axle

Every 50 Hours

  • Check transmission-hydraulic system oil level
  • Clean and check battery
  • Inspect all tires
  • Lubricate front axle pivot pin(s)
  • Lubricate steering spindles
  • Inspect tractor for loose nuts and bolts
  • Lubricate clutch pedal and right hand brake pedal.
  • Lubricate clutch / brake shaft.

First 100 Hours

  • Change engine oil and filter
  • Replace transmission-hydraulic filter

Every 250 Hours

  • Service air cleaner
  • Change engine oil and filter
  • Clean and check battery
  • Inspect and adjust alternator/fan belt
  • Lubricate 3-point hitch
  • Check neutral start system
  • Check clutch pedal free travel
  • Check brake pedal adjustment
  • Replace filter inserts ( primary and secondary alternatively)

IMPORTANT: Never replace primary and secondary inserts simultaneously

Every 500 Hours

  • Replace transmission-hydraulic filter

Every 600 Hours

  • Change MFWD axle oil
  • Clean engine crankcase vent tube
  • Repack front wheel bearings
  • Check and tighten all hoses and hose clamps
  • Check cooling system for leaks
  • Lubricate rear axle bearings
  • Check engine idle speeds
  • Have your John Deere dealer:

    -Check front axle pivot pin

    -Adjust engine valve clearance

    Inspect fuel injectors

    IMPORTANT: External lubrication is not required for oil type rear axle

First 1100 Hours

  • Change transmission-hydraulic oil and filter

Every 1250 Hours

  • Change transmission-hydraulic oil and filter
  • Clean transmission-hydraulic pickup screen

Annually

  • Change engine oil and filter
  • Replace air cleaner elements

Every 2 Years or 2000 Hours (Whichever Comes First)

  • Flush cooling system

Service As Required

  • Service air cleaner
  • Adjust throttle friction
  • Drain water and sediment from fuel tank and fuel filter

1 Only necessary when operating in extremely wet and muddy conditions.
2 Only necessary when operating in extremely wet and muddy conditions

AK50421,000016E-19-20111019
