Inspect Hose Clamps on Air Intake System and Engine Cooling System

LV14658-UN-17AUG11

Left-Side View

LV14659-UN-18AUG11

Top View

A - Engine to Radiator Cooling System (Radiator Supply) Hose Clamp

B - Air Cleaner to Turbocharger Hose Clamp

C - Turbocharger to Charge Air Cooler Hose Clamp

D - Charge Air Cooler Outlet Hose Clamp

E - Engine Intake Hose Clamp

F - Radiator to Engine Cooling System (Water Pump Supply) Hose Clamp

Inspect air intake system and engine cooling system for leaks.

Inspect hose clamps of air intake system and engine cooling system for loose hose clamps and tighten if found.
