Fill Fuel Tank

TS202-UN-23AUG88

CAUTION: Handle fuel with care: It is highly flammable. DO NOT refuel the machine while smoking or when near open flame or spark.

Always stop engine before refueling machine. Fill fuel tank outdoors.

Prevent fires by keeping machine clean of accumulated trash, grease and debris. Always clean up spilled fuel.

Fill fuel tank at end of each days operation. This prevents condensation in tank as moist air cools.

FUEL TANK CAPACITY

Open Station ..............95 L (25 U.S. gal)

IOOS and Cab ..............141 L (37 U.S. gal)

Cab — PowrReverser™ Transmission (PY) ..............126 L (33 U.S. gal)

IMPORTANT: The fuel tank uses a seal filler cap. If a new filler cap is required, always replace it with a sealed cap.

NOTE: To reduce fuel gelling and control wax separation during cold weather, John Deere Fuel Flow Improver, or equivalent, may be added to fuel or bulk storage tank.
