Selecting the Rolling Direction of the Front Tires

RW510-UN-06APR89

A - Rear tire viewed from rear

B - Rolling direction of the tire

C - Tire lugs

1. Under most conditions, the front tires should be mounted with the direction of the tire lugs the same as the tire rolling direction.
2. If the tractor is used mainly with a front loader, the direction of the lugs can be inverted to reduce wear of the tires.
