Daily Service Before Starting Engine

NOTE:

CQ284060-UN-17MAY11

1. Check engine oil level. Clean dipstick (A) and reinsert fully. Withdraw it again and check oil level.

   The window for safe operation of engine is when the oil level is between the upper and lower mark of the dipstick.

   Do not operate the engine if oil level is below minimum mark. In this case, add specified oil. (See "Fuel, Lubricants, Coolant" Section.)

2. Check coolant level of radiator expansion tank. If the engine is cold and coolant level is below LOW, add coolant to expansion tank until level reaches LOW mark. NOTE: With engine cold, coolant level should be at LOW mark. At operating temperature coolant level of a tractor should be at FULL mark

3. Lubricate the following points every 10 hours if operating the tractor in extremely wet or excessively muddy conditions.

   —Front axle pivot pin.

   —Steering transmission shaft.

   —Ends of coupling bar.

4. Check transmission hydraulic oil level. Pull out and clean dipstick. Reinsert it fully again.

   Oil level should be between the marks on the dipstick. If level is low add oil.

Use Universal Grease.

(See "Fuel, Lubricants, Coolant" Section.) for grease specifications.

For more details, see "Fuel, Lubricants, Coolant" section.
