Clean Fuel Tank Vent Filter
CAUTION: Reduce compressed air to less than 210 kPa (2 bar)
(30 psi) when using for cleaning purposes. Clear area of bystanders,
guard against flying chips, and wear personal protection equipment
including eye protection.
LV14431-UN-19AUG11
A - Fuel Tank Vent Filter
Remove and clean fuel tank vent filter (A) and clean with a soapy solution.Blow dry with compressed air and replace.
Replace if damaged.
|
JZ81662,0000A45-19-20120328 |
