Warning Decal — PTO Shield and Drawbar Instructions

PY15244-UN-04JUN12

PY15510-UN-21JUN12

P/N: R212165

A - Warning Decal

To Avoid Bodily Injury:

1. Keep PTO master shield and all power drive system safety shields in place.
2. When operating PTO driven implements, install drawbar in the down position if offset, and use the following drawbar instructions:

PTO Shaft	PTO Shaft End to Hitch Pin Hole
540 rpm, 6 spline	14.00 in (356 mm)
1000 rpm, 21 spline	16.00 in (407 mm)
