Stop Engine

LV15978
LV15978-UN-15AUG12

Hand Throttle (Cab shown)

LV14540
LV14540-UN-02AUG11

LV14811
LV14811-UN-27SEP11

Gear Shift Lever in Park Position

A - Hand Throttle

B - Key

C - Gear Shift Lever in Park Position

IMPORTANT: Before stopping engine that has been operating at working load, idle engine at least 1 or 2 minutes at 1000—1200 RPM to cool hot engine parts. If an Exhaust Filter Cleaning has just been performed, increase engine idle time to 4 minutes.

If service work is going to be performed on the Exhaust Filter, increase engine idle time to 10 minutes.

  1. Pull hand throttle (A) back to low idle.

  2. Check if range shift lever is in NEUTRAL position. If not, depress clutch pedal and place range shift lever in NEUTRAL.

  3. Put gear shift lever in PARK (C), and allow engine to idle for 2—5 minutes.

  4. If equipped, place reverser lever into NEUTRAL.

  5. Lower all equipment to the ground, put all selective control valve levers in NEUTRAL, and disengage PTO.

  6. Turn key (B) to STOP and remove from switch.

JZ81662,000072C-19-20120813
