Brake System Menu

NOTE: The purpose of the brake system menu is to ensure that the machines park brake alone can hold the machine and trailer on an incline or decline when parked.

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

  1. RXA0152976
    RXA0152976-UN-01AUG16

    Brake System Menu

    Locate the brake system menu.


  2. RXA0152977
    RXA0152977-UN-29JUL16

    Trailer Brake Test Selection

    Trailer brake test selection screen appears. Depress the enter/accept button.


  3. Place left-hand reverser in park position with trailer attached. Trailer brake test is not available if machine is in neutral or gear.

    CAUTION: If at any time a “Brake Fault” message appears, a problem in the brake system is detected. See your John Deere dealer immediately for repair.

  4. If “Brake Engaged” message appears, depress the enter/accept button until “Brake Released” appears. The brake test is successful if no “Brake Fault” messages appear.

DP51502,0002639-19-20161215
