Diagnostics Menu

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

1.
   RXA0152980-UN-21JUL16

   Diagnostics Menu

   Locate the diagnostics menu.

---




2.
   RXA0152981-UN-25JUL16

   Trouble Codes Selection


   RXA0152973-UN-21JUL16

   Addresses Selection

   Select and enter the desired selection. See the relevant topic in this section for additional details on selections.

   Selection	Range	Display Response
   Trouble Codes	Trouble codes listed by functional area.	Displays active and stored trouble codes.
   Addresses	Addresses listed by functional area.	Displays addresses that the operator can view or adjust.

---
