SCV and Loader Menu

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

1.
   RXA0152941-UN-01AUG16

   SCV and Loader Menu

   Locate the SCV and Loader menu.

---




2.
   RXA0152942-UN-01AUG16

   SCV I Selection


   RXA0152943-UN-21JUL16

   SCV II Selection


   RXA0152944-UN-21JUL16

   SCV III Selection


   RXA0154074-UN-23SEP16

   SCV IV Selection


   RXA0152945-UN-21JUL16

   SCV XI Selection


   RXA0152946-UN-21JUL16

   SCV XII Selection


   RXA0152947-UN-21JUL16

   SCV XIII Selection


   RXA0152948-UN-21JUL16

   Loader Mode Selection


   RXA0154075-UN-23SEP16

   Advanced Settings Selection

   Select and change the desired settings as needed. See the relevant topic in this section for additional details on settings.

   Selection	Range	SCV Response
   SCV I SCV II SCV III	Flow 1—10 Time 0—180 seconds or continuous	Higher values provide more/faster flow. Higher values provide longer times the SCV is at maximum flow.
   SCV IV	ON or OFF	When used with the hydraulic top link, ON will cause top link to extend.
   SCV XI SCV XII SCV XIII	Flow 1—10 Time 0—180 seconds or continuous	Higher values provide more/faster flow. Higher values provide longer times the SCV is at maximum flow.
   Loader Mode	ON or OFF	Loader mode ON disables SCV XI, XII, and XIII timed detents (defaults to 0 seconds) and enables bucket rattle function.
   Advanced Settings	Linear (On-Off), Progressive (variable), or Combination	Flow sensitivity can be adjusted to match the requirements of the application.

---
