Engine Menu

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

1.
   RXA0152958-UN-21JUL16

   Engine Menu

   Locate the engine menu.

---




2.
   RXA0152959-UN-21JUL16

   FieldCruise Selection


   RXA0152960-UN-21JUL16

   Auto Filter Cleaning Selection


   RXA0152961-UN-21JUL16

   Filter Cleaning Selection

   Select and change the desired settings as needed. See the relevant topic in this section for additional details on settings.

   Selection	Range	Engine Response
   FieldCruise™	1050—2250	Engine upper rpm is restricted to the FieldCruise™ setting
   Auto Filter Cleaning	Automatic Cleaning or Cleaning Disabled.	Automatic cleaning allows exhaust filter cleaning to occur during operation if certain conditions are met. Cleaning disabled prevents automatic cleaning. When the engine is cycled off it defaults back to automatic.
   Filter Cleaning	Parked Filter Cleaning.	If the symbol is not grayed out, a parked filter cleaning can be performed.

---
