Maintenance Counters and Intervals

RXA0152975-UN-01AUG16

Service Interval Icon

Service Intervals:

To remind the operator when the next machine service is due, set service interval to next required hour interval. The service interval is changed in the maintenance menu.

20 hours before the service interval is due, the system informs the operator that the machine needs service soon. Once the message has been acknowledged, the system informs the operator about the upcoming service at every start-up until service interval is reset.

RXA0152974-UN-21JUL16

Service Counter Icon

Service Counter:

Service interval is displayed with the elapsed time since the last reset. When service is completed, the counter is reset by depressing the enter/accept button for 3 seconds.
