Rear Hitch Menu

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

1.
   RXA0152936-UN-21JUL16

   Rear Hitch Menu

   Locate the rear hitch menu.

---




2.
   RXA0152937-UN-21JUL16

   Load Depth Selection


   RXA0152938-UN-21JUL16

   Upper Limit Selection


   RXA0152939-UN-29JUL16

   Drop Rate Selection


   RXA0152940-UN-21JUL16

   Raise Rate Selection

   Select and change the desired settings as needed. See the relevant topic in this section for additional details on settings.

   Selection	Range	Hitch Response
   Load Depth	Position Control 0.0 Depth Control 1.0—5.0	Position control is for implements with gauge wheels. Higher values provide more/faster draft response.
   Upper Limit	10—100	Higher values make the hitch raise higher.
   Drop Rate	1.0—5.0	Higher values make the hitch drop faster.
   Raise Rate	1.0—5.0	Higher values make the hitch raise faster.

---
