Transmission Menu

NOTE: For additional navigation information, see “Basic Menu Navigation” in the Displays, Software, and Electronics Operation section.

1.
   RXA0152949-UN-21JUL16

   Transmission Menu

   Locate the transmission menu.

---




2.
   RXA0152950-UN-21JUL16

   PowrReverser Selection


   RXA0152951-UN-21JUL16

   Min rpm Selection


   RXA0152952-UN-21JUL16

   ECO-Min rpm Selection


   RXA0152953-UN-21JUL16

   Rev/Fwd Ratio Selection


   RXA0152954-UN-21JUL16

   Load Anticipation Selection


   RXA0152955-UN-21JUL16

   Start Gears Selection


   RXA0152956-UN-21JUL16

   Droop-PTO Off Selection


   RXA0152957-UN-21JUL16

   Droop-PTO On Selection


   RXA0153891-UN-19SEP16

   AutoClutch™ Selection

   Select and change the desired settings as needed. See the relevant topic in this section for additional details on settings.

   Selection	Range	Transmission Response
   PowrReverser	1—10	Higher values make direction changes more aggressive and quicker.
   Min rpm	900—2150	Sets the lowest engine rpm while in AUTO mode.
   ECO-Min rpm	900—2150	Prevents engine rpm from dropping below a set minimum engine speed when in ECO mode.
   Rev/Fwd Ratio	Fx0.2—Fx2.0	Allows for setting the forward to reverse speed ratio.
   Load Anticipation	PTO or Hitch	Transmission downshifts or engine speed increases when the PTO or hitch is engaged.
   Start Gears	BCD start gear and CD start gear.	Allows for setting the desired start gear for BCD and CD button selection.
   Droop-PTO Off	Low—High	Low makes the transmission downshift earlier when engine speed is reduced with PTO Off.
   Droop-PTO On	Low—High	Low makes the transmission downshift earlier when engine speed is reduced with PTO On.
   AutoClutch™	High—Low and Off	Higher settings make the AutoClutch™ engage more aggressive and quicker.

---
