Engine Block Coolant Heater

A - Engine Block Coolant Heater

  1. IMPORTANT: Before connecting heater to a power source, be sure that element is immersed in coolant. NEVER energize the heater in air. Doing so can cause the element sheath to burst causing personal injury.

    Locate the block coolant heater (A) on the right-hand side of the engine.

  2. Connect heater plug to a 230 volt outlet protected by ground fault interrupter.
