Stop Engine

RXA0152805
RXA0152805-UN-13JUL16

Left-Hand Reverser

RXA0152460
RXA0152460-UN-21JUN16

Hand Throttle

A - Hand Throttle

IMPORTANT: Idle engine that has been operating at working load at least 1 or 2 minutes at 1000—1200 rpm to cool. If an exhaust filter cleaning has just been completed, increase engine idle time to 4 minutes.

  1. Place left-hand reverser in Park position.

  2. Place hand throttle (A) to idle position.

  3. Disengage PTO.

  4. Lower any equipment the ground.

  5. Place SCV levers in neutral position.

  6. Lower hitch completely if an implement is attached.

  7. Turn key to stop and remove.

MP60050,000094A-19-20161121
