Inspect Machine Daily Before Starting

Perform periodic service checks in the Maintenance-Every 10 Hours or Daily chapter.

  • Check and lubricate loader pivot pins (A).
  • Check engine oil level and air cleaner (B).
  • Check precleaner (C).
  • Check hydraulic oil level (D).
  • Clean operator's station (E).
  • Check and lubricate backhoe pivot pins (F).
  • Check pedals and controls (G) for freedom of movement.
  • Check inflation pressure of tires (H) and torque of wheel hardware.
  • Clean radiator fins (I).

ELECTRICAL SYSTEM: Check for worn or frayed wires and loose or corroded connections.

HYDRAULIC SYSTEM: Check for leaks, missing or loose clamps, kinked hoses, and lines or hoses in areas that rub against each other or other parts.

BACKHOE AND LOADER: Check for loose, bent, broken or missing parts and hardware.

LUBRICATION: Check lubrication points shown on Greasing Maintenance Chart or in Maintenance-Every 10 Hours or Daily chapter. (See Service Your Machine at Specified Intervals in Periodic Maintenance chapter for location of greasing maintenance chart.)

PROTECTIVE DEVICES: Check ROPS, guards, shields, covers, seat belt, and reverse warning alarm.

FIRE PREVENTION: Clean machine of debris.

PARK BRAKE: Check for correct operation.

SAFETY: Walk around machine to ensure all persons are clear from machine area.

T132586


A-Loader Pivot Pins
B-Engine Dipstick and Air Cleaner
C-Precleaner
D-Hydraulic Oil Level Sight Tube
E-Operator's Station
F-Backhoe Pivot Pins
G-Pedals and Controls
H-Tires
I-Radiator Fins

CED,OUO1079,468 -19-17JUL00-1/1
