Lubricate 4-in-1 Bucket Pivots-If Equipped

T132371C

2 Points
T132372C

4 Points-Left Side Shown

Apply grease to lubrication fittings until it escapes from joints. (See Fuels and Lubricants chapter for recommended type of grease.)

CED,OUO1079,581 -19-24AUG00-1/1
