Lubricate Loader Pivots

Apply grease to lubrication fittings until it escapes from joints. (See Fuels and Lubricants chapter for recommended type of grease.)

T134630C

6 points-Right Side Shown

T132371B

9 points

T132372B

2 Points-Left Side Shown

OUO1079,000025B -19-11SEP00-1/1
