STOP Indicator and Alarm

IMPORTANT: If STOP indicator lights and alarm sounds for more than ten seconds with engine oil pressure indicator lit, stop machine immediately and investigate cause of problem.

If STOP indicator lights and alarm sounds for more than ten seconds with engine coolant temperature gauge needle in red zone, reduce load and run engine for 1-2 minutes at slow idle to allow time to cool. If STOP indicator remains lit and engine coolant temperature gauge needle does not fall to an acceptable operating temperature, stop engine and investigate problem. Do not restart engine until problem has been corrected.

The STOP indicator lights and alarm sounds when:

  • Engine oil pressure is low.
  • Engine coolant temperature is excessively high.
  • Hydraulic oil temperature is excessively high.
  • FNR/range lever is shifted into FORWARD or REVERSE with park brake ON.
  • FNR/range lever is shifted into FORWARD or REVERSE with park brake OFF and seat rotated toward the backhoe position.

If indicators do not function correctly, see Troubleshooting chapter.

T7673AM

OUO1079,00002B4 -19-23OCT00-1/1
