Service Required Indicator

If service required indicator on monitor panel lights, a problem is developing. It is not necessary to stop the engine immediately, but the cause should be investigated as soon as possible.

The service required indicator lights when:

  • Engine alternator voltage is low.
  • Engine air filter is restricted.
  • Transmission oil filter is restricted.
  • Hydraulic oil filter is restricted.

NOTE: Cold oil may cause transmission filter restriction indicator and hydraulic filter restriction indicator to light.

T6201BL

CED,OUO1079,42 -19-29MAR00-1/1
