F1-10 Amp Park Brake and Reverse Alarm Fuse
F2-10 Amp Starter and Park Start Fuse
F3-7.5 Amp Differential Lock and Grapple Rotate Fuse
F4-10 Amp Secondary Steering Fuse-If Equipped
F5-5 Amp Radio Fuse-If Equipped
F6-10 Amp Starting Aid Fuse-If Equipped
F7-10 Amp Horn Fuse
F8-10 Amp Front Washer and Wiper Fuse
F9-10 Amp Fuel Shut-Off Fuse
F10-10 Amp Transmission Controller Input Power Fuse
|
F11-10 Amp Transmission Controller Output Power Fuse
F12-5 Amp Monitor Battery and Voltage Input and Radio Fuse (Unswitched)
F13-5 Amp Monitor Fuse (Switched)
F14-20 Amp Heater Fuse
F15-5 Amp Temperature Control Fuse
F16-25 Amp High Speed Blower Fuse
F17-30 Amp Purge Blower Fuse
F18-15 Amp Front Work Lights Circuit Breaker
F19-15 Amp Rear Deluxe Lights Circuit Breaker-If Equipped
|
F20-20 Amp Air Seat Fuse-If Equipped
F21-5 Amp Dome Light Fuse-If Equipped
F22-10 Amp Precleaner Fuse-If Equipped
F23-10 Amp Spare Fuse
F25-15 Amp Rear Work Lights Circuit Breaker
F27-10 Amp Rear Washer and Wiper Fuse-If Equipped
F28-15 Amp Accessory Plug Fuse
F29-15 Amp Accessory Connection Fuse
F30-5 Amp Work Lights Fuse
|
F31-15 Amp Front Deluxe Lights Circuit Breaker-If Equipped
F32-5 Amp A/C Defrost Fuse
K1-Accessory Relay #1
K2-Accessory Relay #2
K4-Park Brake Reset Relay
K5-Park Start Relay
K7-Front Work Lights Relay
K8-Rear Work Lights Relay
K9-Transmission and Monitor Relay
K10-Heater Blower Relay
K11-High Speed Blower Relay
K12-Purge Blower Relay
K13-Horn Relay
|
