Lubricate Frame Hinge Pivot

CAUTION: Prevent possible injury from unexpected machine movement. Install frame locking bar before lubricating.

Apply three shots of grease to each point. (See Fuels and Lubricants chapter.)

NOTE: Grease daily when operating in severe conditions such as deep mud, water, or snow.

CED,OUO1002,454 -19-20FEB98-1/1
