Prepare Machine For Storage

2. Clean primary air cleaner.

TX,105,FF2313 -19-03APR91-1/3

IMPORTANT: High pressure washing [greater than 1379 kPa (13.8 bar) (200 psi)] can damage freshly painted finishes. Paint should be allowed to air dry for 30 days minimum after receipt of machine before cleaning parts or machines with high pressure. Use low pressure wash operations until 30 days have elapsed.

3. Wash the machine. [Use low pressure wash operations (less than 1379 kPa (13.8 bar) (200 psi)) until 30 days after receipt of machine have elapsed.] Paint areas to prevent rust. Replace decals, where needed.

4. Apply waste oil to track chains. Run machine back and forth several times. Park machine on a hard surface to prevent tracks from freezing to ground.

5. Store machine in a dry, protected place. If stored outside, cover with a waterproof material.

IMPORTANT: LPS ® 3 Rust Inhibitor can destroy painted finish. Do not spray LPS ® 3 Rust Inhibitor on painted areas.

6. Retract all hydraulic cylinders, if possible. If not, coat exposed cylinder rods with LPS ® 3 Rust Inhibitor.

LPS is a registered trademark of the Holt Lloyd Corporation.

TX,105,FF2313 -19-03APR91-2/3

IMPORTANT: Prevent possible machine damage from unauthorized persons operating machine. Attach a "DO NOT OPERATE" tag to right control lever.

7. Place a "DO NOT OPERATE" tag on the right control lever.

8. Move battery disconnect switch to OFF position.

9. Lubricate all grease points.

10. Remove batteries.

11. Remove seat cushion and other perishable items.

12. Remove keys and lock all covers and doors.

TX,105,FF2313 -19-03APR91-3/3
