Safety Label Location (62 in. Rear Discharge)

TCT008389-UN-19FEB14

Use label number listed in table below to locate complete text of safety label message following this illustration. Pictorial labels are required for certain parts of the world. Your machine may not be equipped with these labels.

A - AVOID INJURY AND READ OPERATOR’S MANUAL M139475

B - AVOID INJURY FROM ROTATING BLADES M118041

C - AVOID INJURY FROM ROTATING BLADES AND THROWN OBJECTS M118040

D - AVOID INJURY FROM ROTATING SHAFTS AND DRIVELINES M119516
