Front Windshield Wiper

LV30423
LV30423-UN-12MAR19

Front Windshield Wiper Switche

LV30416
LV30416-UN-12MAR19

Washer Fluid Reservoir

A - Front Windshield Wiper Switch

B - Fluid Reservoir

To turn the front windshield wiper on and off, use the wiper switch (A).

The washer fluid reservoir (B) is located under the hood of the tractor. Fill the reservoir with windshield washer fluid as required. In cold climates, fill with non-freezing windshield washer fluid. Reservoir only supplies the front wiper.

UP00731,00008E6-19-20190312
