Safety Label Location—XUV590 S4 (Bucket Seat)

MXT020161-UN-24MAY17

A - Help Prevent Injury when Dumping Loads M165565 (Machines with Power Lift)

B - Avoid Injury from Crushing M177389

C - Avoid Injury or Death from Rollover or Falling Off M165375

D - Read Operators Manual, Service Battery SU49461

E - Avoid Injury From Battery Gases and Acid M133159

F - Protective Structure Safety and Certification UC13991

G - Avoid Injury from Fire M165368

H - Avoid Injury M160658 (On Optional Front Rack)

I - Avoid Injury or Death from Falling Off M165365

J - Avoid Injury or Death from Rollover or Falling Off M168539

K - Read Operators Manual, Jacking Point SU48175

L - Avoid Injury From Equipment Fires M165273

M - Avoid Injury or Death from Rollover or Falling Off M165362
